| NO。OF Phases/絲桿電機相數 | 2P | Motor Length/電機長度 |
47MM |
| Step angle/絲桿電機步距角 | 1.8o ±5% | Insulation Class/絕緣等級 | B |
| Rated voltage/額定相電壓 |
3.3 V |
Working Temperature/工作溫度 | -20OC~~+50OC |
| Rated current/額定相電流 | 1.5A | Insulation Resistance/絕緣電阻 | 100MΩ（500VDC） |
| Resistance/相電阻 | 2.2Ω | Temperature Rise/溫升 | 80K MAX。 |
| Deceleration ratio/減速比 | 1:25 | Weight/電機重量 | 820g |
| Installation dimensions/安裝尺寸 | 42*42 | Holding torque/保持力矩 | 10N。M |
|
|
|
|
|
|
|
|
|
|
